2. Ex marking
Ambient temperature range
Depending on the application, the following surface temperature and ambient
temperature ranges apply:
Application
Group II (gas)
Group III (dust)
1) Limited by the permissible ambient temperature of the device, for further information see chapter „Specifica-
tions" in the operating instructions.
The special conditions from the type examination certificate (see chapter 5 „Special
conditions for safe use (X-conditions)") apply.
Transmitter models T38.x
The externally connected cabling or wiring shall be suitable for the temperature range
(max. 85 °C [185 °F] (or 105 °C [221 °F])) of the end-use application. The conductor
cross-section must be a minimum of 0.14 mm².
Operation in Ex areas for all zones
Operation in a hazardous atmosphere requiring category 1 equipment is only permitted
when the following atmospheric conditions exist:
Pressure: 0.8 ... 1.1 bar [11.60 ... 15.95 psi]
Operation in Ex areas for zone 1 und zone 2
The electrical parameters of the head- and rail-mounted versions are identical.
For T38.*-AI**: The intrinsically safe sensor circuit (optional 2-wire, 3-wire or 4-wire
configuration) for both versions is intended for the supply of equipment in areas with 1G
or 1D requirements.
The version T38.H-AI** has been designed for installation in cases or connection heads
in areas with zone 0, 2G or zone 20, 2D requirements.
The version T38.R-AI** is intended for installation in a case which guarantees at least
IP20 ingress protection (2G application or installation outside the hazardous area) or
IP6X (2D application).
WIKA additional operating instructions, models T38.x
Ambient temperature
range
1)
-50 ... +105 °C [-58 ... +221 °F]
-50 ... +85 °C [-58 ... +185 °F]
-50 ... +75 °C [-58 ... +167 °F]
-50 ... +60 °C [-58 ... +140 °F]
-50 ... +50 °C [-58 ... +122 °F]
-50 ... +40 °C [-58 ... +104 °F]
-50 ... +70 °C [-58 ... +158 °F]
-50 ... +100 °C [-58 ... +212 °F]
Temperature Power P
class / Surface
temperature
T4 600 mW
T4 800 mW
T5 800 mW
T6 600 mW
T6 800 mW
T135 °C 750 mW
T135 °C 650 mW
T135 °C 550 mW
