5. Special conditions for safe use (X-conditions)
5.2.7 Transmitter model T38.R-*E*** (rail-mounted version, Ex ec)
The transmitter must be mounted in a case that meets a minimum ingress protection
■
of IP54 in accordance with IEC 60079-0 and in which electrostatic charging effects
are excluded.
The instrument must be installed in an area with at least pollution degree 2.
■
EN
The use of the PU + and - connections is only permitted outside of the Ex
■
atmosphere and if the + and - connections are not connected.
5.3 CSA approval
5.3.1 Transmitter model T38.x-CI**
These models are designated for installation inside a suitable enclosure providing
■
degree of protection at least IP20 for EPL Ga or Gb application.
The enclosure may be located in EPL Ga area (zone 0), EPL Gb area (zone 1), or
■
optionally in the safe area.
The influence of power dissipation of other devices placed beside the transmitter has
■
to be taken into account with regard to temperature rise of the transmitter's ambient
temperature.
During the installation internal wiring, clearances, creepage distances and separa-
■
tions have to be considered according to CAN/CSA C22.2 No. 60079-11
5.3.2 Transmitter model T38.x-CI**
These models are designated for installation inside a suitable enclosure providing
■
degree of protection at least IP20 for EPL Gc application.
The enclosure may be located in EPL Gc area (zone 2), or optionally in the safe area.
■
The influence of power dissipation of other devices placed beside the transmitter has
■
to be taken into account with regard to temperature rise of the transmitter's ambient
temperature.
During the installation internal wiring, clearances, creepage distances and separa-
■
tions have to be considered according to CAN/CSA C22.2 No. 60079-11.
