Quadrum DigiPlus / Quadrum DigiPlus Green
Please read the operating instructions as well as the enclosed brochures „Guarantee and
!
additional notices" and „Laser class 3R safety instructions". Follow the instructions they
contain. Safely keep these documents for future reference.
Two-axis grade laser with red or green laser technology.
– With additional red plumb laser
– Laser modes: spot, scan, rotary and hand receiver mode
– The laser modes can be set using the remote control.
– optional SensoLite 410: Laser receiver range up to 400 m radius
– optional SensoMaster 400 (Quadrum DigiPlus red only): Laser receiver range up to 400 m radius.
With longer laser receiver unit and millimetre exact distance reading for laser level.
General safety instructions
Caution: Prior to using the laser, you must read the safety instructions for laser class 3R thoroughly.
Warning signs must not be removed from the laser measuring device! Do not look directly into the
beam. Lasers must be kept out of reach of children. Never intentionally aim the device at people.
This is a quality laser measuring device and is 100% factory adjusted within the stated tolerance. For
reasons of product liability, we must also draw your attention to the following: Regularly check the
calibration before use, after transport and after extended periods of storage. We also wish to point
out that absolute calibration is only possible in a specialist workshop. Calibration by yourself is only
approximate and the accuracy of the calibration will depend on the care with which you proceed.
Special product features and functions
The rotary laser aligns itself automatically. It is set to the required initial position (to within
an operating angle of ± 6°) and the automatic system then performs the necessary fine
adjustment, with three electronic measurement sensors detecting the X, Y and Z axes.
Transport LOCK: The device is protected by a special motor brake during transport.
The device characterised by specific protection against dustand rain.
IP 66
Laser radiation!
Do not stare into
the beam!
Laser class 2
< 1 mW · 635 nm
EN 60825-1:2007-10
Laser radiation!
Avoid direct exposure
to the eyes.
Laser class 3R
EN60825-1:2007-10
