Assembly
Installation in profile tubes / installation in round
tubes
1
Insert drive with matching adapter and limit switch
tappet ring in the profile pipe.
1a
Only when installing in the round tube:
On round tubes, cut a slot in the end of the tubes
on the drive side (width 4 mm, length 16 mm)!
1b
Push the drive into the round tube and place it so
that the tappet wedge (the inner groove) fits into
the intended cut-out.
2 Secure the counterpart support to prevent axial
movement, e.g. screw or rivet on the idler.
3 Screw in the coupling (adapter) or rivet it (for round
tube only). Secure the drive in the motor-bearing
against axial movement,
4 Attach the roller shutter to the shaft. If the applica-
tion can only be attached to a twisted winding shaft,
switch on the drive in direction downwards until the
drive switches off at the bottom end point (lower
end of the running path reached).
The drive is connected to the profile tube/round tube.
Installation in profile tube/round tube
The drive is connected to the profile tube/round tube.
5.2 Electrical connection
WARNING
Danger to life due to faulty electrical connection.
Electric shock possible.
►Before commissioning check the correct connection of
the PE conductor.
NOTES
Damage to the VariEco by faulty electrical connection.
►Before commissioning check the correct connection of
the PE conductor.
Damage or destruction of VariEco by the penetration of
moisture.
►For units with protection class IP 44, the customer con-
nection of the cable ends or connector (cable bushing)
must also be carried out in accordance with protection
class IP 44.
Damage or destruction of VariEco for variants with 230 V
AC 1 due to faulty control.
►Switch with OFF setting (Dead man) for drives must be
installed within sight of the VariEco, but away from any
moving parts and amounting to about 1.5 m.
4 | EN
1
2
3
4
© elero GmbH
►The motor control must be interlocked in UP/DOWN
direction. A reversing delay of 0.5 seconds must be
ensured.
►Parallel switching of several VariEco drives is only possi-
ble with separating relay.
Damage to the application from incorrect running direction
►The assignment of the running direction UP/DOWN must
be reviewed after the electrical connection has been
established.
Adjustment of the end position at the drive.
►Any adjustment of the end positions that occurs indicates
an electrical connection error. Readjustment of the end
positions is not sufficient in this case, since the end
positions are adjusted often. In this case, the drive needs
to be replaced and the cause removed.
Important
Permanently installed control devices shall be clearly dis-
played.
Important
If the VariEco is used in locations that are not "dry rooms"
(e.g. in the outdoor area, in wet rooms or if it is excluded
that the roller shutter boxes are reliably protected from
moisture by their construction or by roof protrusions and
similar things), the drive must be installed with connection
lines suitable for the installation situation or the connection
lines must be protected by conduits. This also applies to
protection from direct solar irradiation.
All applicable standards and provisions must be observed
for the electrical installation.
When connecting the drive to a control, the operating
instructions of the control must be observed.
►Only perform connecting work with the power turned off.
5.3 Connection example VariEco 230 V / 50 Hz
Capacitor
Final limit
switch
Motor cable
plug
Mains 230 V/50 Hz
Fig. 4 Circuit diagram VariEco with 230 V / 50 Hz
Winding thermostat
Junction box
(outside of roller shut-
ter case)
Switch box
