INSTRUCTION MANUAL
ACDCTIG-200P Welding machine
TECHNICAL INFORMATION
>> Model: ACDCTIG-200P
>> Welding methods: AC / DC TIG, PULS TIG, MMA
>> Connection voltage: 230V / 50 / 60Hz
>> TIG DC welding current range: 5-200A
>> TIG AC welding current range: 20-200A
>> MMA welding current range: 20-160A
>> Idle voltage: 80V
>> Pre-flow: 0-10s
>> Post-flow: 0-25s
>> Pulse frequency: 1Hz or 50Hz
>> AC frequency: 20-250Hz
>> Cleaning effect (AC balance): 10-90%
>> Final current: adjustable
>> TIG load factor: 200A / 35% / 160A / 60% / 130A / 100%
>> MMA load factor: 160A / 35% / 130A / 60% / 100A / 100%
>> MMA electrode diameter: 1,0-4,0mm
>> TIG electrode diameter: 1,0-3,2mm
>> High frequency ignition: Yes
>> Forced fan cooling
>> Insulation class: F
>> Protection class: IP21S
>> Dimensions: 430 × 185 × 320mm
>> Weight: approx. 13,5kg
