Batteries
Charging the
batteries
Mount suction nozzle
www.cleanfix.com
• Mount the batteries as shown in Fig. 4 and connect the connector (E, Fig. 4).
• Charge the batteries of the machine using the charging cable.
(see description below)
• Fill the freshwater tank as required, maximally up to the marking on the level
indicator. (Fig. 8, page 33)
The machine is built for direct current 24V. Two 12-volt batteries are used, connected
in series. (Picture 4)
Check whether the plug connection (E, Fig. 4) is correctly pushed together.
The machine may only be operated with wet or maintenance-free batteries.
Li-ion batteries are prohibited.
Connect the power cable to the mains and plug it into the device (1) provided for this
purpose. (Fig. 5)
Always pull on the plug housing, not on the cable. Carry out charging according to the
battery type and the manufacturer's instructions.
Intermediate charging during work is not recommended.
After charging, disconnect the power cord from the machine and the mains.
-
+
E
Loosen the star grips (1) on the suction nozzle until they can be pushed onto the
nozzle carrier (2) (Fig. 6).
Tighten the star knobs (1) hand tight.
Attach the suction hose (3) to the suction nozzle.
The suction nozzle can be lowered and raised using the handle (4, Fig. 7)
1
2
3
+
-
4
2
1
6
32
1
5
4
7
435.042
