Structure and function
www.cleanfix.com
1 Start lever
2 Handle for lowering suction nozzle
3 Steering handle
4 Lever height adjustment steering handle 18 Discharge hose for wastewater
5 Fresh water filler opening
6 Filter with float
7 Dirty water tank cover
8 Dirty water tank
9 Fresh water tank
10 Suction nozzle
11 Brush head
12 Scrubbing brush
13 Deflection roller brush head
14 Wheel
3
5
6
5
23
10
14
13
2
18
20
21
23
24
15 Suspension additional pad or brush
16 Display
17 Fresh water level indicator
19 Charging cable socket
20 Suction hose
21 Sight glass with freshwater filter
22 Water quantity dosing
23 Freshwater drain
24 Deflection rollers Suction nozzle
25 Batteries
26 Brush motor circuit breaker
27 Type plate
1
2
7
8
15
9
11
12
16
5
4
25
17
27
19
22
24
10
30
26
