Netzsicherheit
[ Netzsicherheit > MACsec > MKA-Session ]
4.10.4
MACsec MKA-Session
[ Netzsicherheit > MACsec > MKA-Session ]
This dialog displays the information about the current MACsec Key Agreement (MKA) session
active on MACsec-capable ports.
[<Port
number>]
Information
Status
Displays the current state of the MKA session.
The state of the MKA session is
created a Secure Channel (SC). If the SC is not created or has failed, the state is Unsecured.
Lokaler TxSCI
Displays the 64-bit identifier that identifies the SC used to send he
from this port. It is a concatenation of the device MAC address and port ID.
MKA-Port-Kennung
Displays the unique port ID that the MKA protocol uses to identify the port in the MKA session.
CAK-Name
Displays the name of the Connectivity Association Key (CAK) used for peer authentication.
Schlüssel-Server
Displays whether the device acts as the key server for generating the Secure Association Keys
(SAKs).
MAC-Adresse
Displays the MAC address of the device associated with the port used in the MKA session.
Mitglieds-Bezeichner
Displays the unique identifier the MKA protocol assigns to the local device in the MKA session.
Nummer der Nachricht
Displays the latest MKA message number assigned by the MKA protocol to track the current
session state.
266
Secured
when the device and its peer device have successfully
protected data packets
MACsec
RM GUI BRS
Release 10.3 04/2025
