MIG-225SYN
Welding wire diameter in mm
0,6
0,8
1,0
Attention: when adjusting the welding wire 1mm, the range is 2-8. If you set it to more than 8, the
appliance will always return the setting to 8.
It is also possible to set the welding voltage U and the inductance Ind. Inductance you set in the same
way as in MIG AUTO mode. However, you must also set the weld voltage U. The setting is reached by
pressing button 8 until display A the letter U is displayed, then set the desired voltage with potentiometer
9 within 1-2 seconds. We advise you to voltage between 18 and 20V and then adjust as needed
according to set the wire feed and the weld itself.
MMA Mode
Press the button 7 to select the MMA mode
MMA mode is used for coated electrode welding.
VRD
Press button 3 to switch VRD (Voltage reduction) on or off. When VRD is on, it is idle voltage (when not
welding) reduced to about 20V. We advise always involved VRD.
Welding current
Set the welding current by turning potentiometer 9.
HS, DIG and ANT settings
The following settings are also possible. Press button 8 to select between HS, DIG and ANT.
HS - Hot Start - The start of the weld seam is heated more quickly and prevents the stick electrode from
sticking when welding starts, which is achieved thanks to the automatic superimposition of the welding
current.
Setting range 0-10, we recommend setting the value 5 initially and readjusting this later, depending on
the type of electrode.
DIG - ARC Force - The welding current is electronically adjusted for different arc lengths.
Setting range 0-10, we recommend setting the value 5 initially and readjusting this later, depending on
the type of electrode.
ANT - Anti Stick - Prevents the stick electrode from sticking by limiting the current shortly before the
short circuit.
Setting option: On / Off - On / Off
LIFT TIG mode
Pressing button 7 selects LIFT TIG mode In Lift TIG mode, welding can be done using the TIG process
with the optional TIG burner (not included in the package).
Welding current
Only the welding current can be set with potentiometer 9. At idle, the display will show between 15 and
22V, the value will change several times per second which is normal, between welding the voltage will
stabilize.
Setting Wire speed (mm/s)
2-15
2-15
2-8
13
80-345
80-345
80-210
