MIG-225SYN
IPOTOOLS MIG SYN allows fine settings of all welding parameters. By pressing button 8 you can
choose from the settings:
- Cur - welding current
- Ind - inductance
- Arl - Arc length
Cur - welding current
You can also adjust the welding current without pressing button 8, easily to set the welding current just
turn potentiometer 9. To adjust Ind and Arl, you must first press button 8 and by pressing it again select
the parameter you want to set. Then you have approx. 1-2 seconds to set the desired parameter by
turning potentiometer 9.
Ind - inductance
Ind - range -10 to +10 - this sets the arc concentration. -10 - narrow and high weld, +10 wide and low
weld.
Arl - Arc length
Arl - range -10 to +10 - the device in MIG AUTO mode sets the welding voltage itself, with Arc the length
parameter determines the deviations from this voltage. E.g., the appliance is automatic sets the voltage
to 18V and Arl is set to -5 - this means that the welding voltage will be 13V. That is a very important
parameter that determines the heat input to the weld. -10 will make you cold weld while +10 very hot.
We recommend an initial setting of -5 and then after adjusting these settings.
Possible ranges of welding current in MIG AUTO mode:
Welding wire diameter in mm
0,6
0,8
1,0
MIG Mode
Press the button 7 to select the MIG mode
In this mode, all welding parameters are set manually. The use of this method is not recommended,
because MIG AUTO mode is much more convenient and allows superior welding results. If you will only
ever want to use manual mode, however, we provide setup instructions.
Gas selection
The selection of shielding gas is performed in the same way as in MIG AUTO mode, with the difference
that in MIG mode can also be chosen by welding with filled wire without the use of shielding gas. The
following light will be lit in this selection:
2T-/4T- mode
Select 2T / 4T mode and welding wire diameter in the same way as in MIG AUTO mode.
Adjust the welding current with potentiometer 9. In MIG mode, do not set the welding current in Amperes
but the speed of the wire. Possible setting ranges:
Welding current range
40-225A
60-225A
70-225A
