4. COMMISSIONING REPORT
EN
Elexant 550c-Modbus
DE
SERIAL-NUMBER:
FR
DA
PARAMETER
SETPOINT °C
CZ
LOW TEMP. SETPOINT
PL
HIGH TEMP. SETPOINT
IT
SENSOR NUMBER
SENSOR LENGTHS
HEATING CABLE
RCD
CB TYPE
INSTALLER COMPANY
INSTALLER NAME
5. TECHNICAL SPECIFICATIONS
HEATING CABLES
Electrical Properties
Supply voltage
Power consumption
Output relay / contactor /
heating cable
Power supply terminals
Heating cables contactor
terminals
Alarm terminals
Modbus terminals
Sensor terminals
Alarm relay
Real time clock
Clock back up
Clock accuracy
Settings
Exposure temperature
Storage temperature
Enclosure
Material
Dimensions
Ingress protection class
Weight
Mounting
Flammability class
|
6
nVent.com/RAYCHEM
Project location:
Date:
HEATING ZONE 1
nVent RAYCHEM HWAT-R, HWAT-M and HWAT-L
230 VAC –15/+10%; 50/60 Hz
Max. 25 VA
2 x 4 A / 230 VAC
3 x 1,5 mm²
2 x 2 x 1,5 mm²
3 x 1,5 mm²
3 x 1,5 mm
2
2 x 2 x 1,5 mm²
Single pole double throw relay, voltage-free, rating
2 A/250 VAC
Automatic summer/winter time and leap year
correction
3 years
Typ. +/–10 minutes / year
All settings are stored in a non-volatile memory
0°C to +40°C
−20°C to +50°C
PPE (polyphenylene ether)
158 mm x 110 mm x 56 mm
IP20
550 g
DIN-Rail mountable 35 mm
UL94-V1
HEATING ZONE 2
mA
mA
