nVent RAYCHEM Elexant 550c-Modbus Installations- Und Bedienungsanleitung Seite 3

D1
Optional boiler sensor (S2) position
Min. 200 mm
Min. 200 mm
Insulation
D2
Optional pipe line sensor (S1) position
Alu tape
Sensor tip
Insulation
HWAT-L/-M/-R
Sensor positioning
on metal pipes
HWAT-R/-M/-L
Pipe/boiler coupling
HWAT-ECO sensor
Aluminium tape
Boiler
Metal pipe
Sensor positioning
on plastic pipes
ATE-180
Boiler
Note: For plastic pipes
position sensor on metal
boiler coupling
Alu tape
Plastic pipe
Sensor tip
Insulation
HWAT-L/-M/-R
