7.3.3 Connect to the Solar Panels

1. The SolarFlow 800 Pro features four independent MPPTs, with each PV input operating as an isolated MPPT
• Open Circuit Voltage (Voc): Must be below 55V per PV input.
• Short Circuit Current (Isc): Must be below 22.5A per PV input.
• Recommended Power Range: Each PV input supports solar panels rated between 400W and 900W.
2. For optimal inverter efficiency, it is recommended to use a solar cable that is 3 meters or shorter. This ensures
reduced energy loss during transmission.
(1) Connect one solar panel to the SolarFlow 800 Pro
Ensure you measure the distance and install the solar panels in the desired location before connecting them
to the SolarFlow 800 Pro.
• The positive and negative terminals of a single solar panel must be connected to the same PV port.
(2) Connecting Solar Panels in Parallel
• Ensure the combined Voc (open circuit voltage) of the panels connected to a single PV input is below 55V.
• The total current for a single PV input must not exceed Isc (short circuit current) 22.5A.
12
400W~900W
400W~900W
