Description of the control unit
It is always made of plastic materials and consists of the three following main parts:
1. Black central body.
2. Orange door with handle, which protects the control panel.
3. Black cover with gasket for the protection of electrical
connections.
The front part also includes:
4. Emergency mushroom-shaped button
5. Red warning light. When it is on, it indicates that the tarpaulin is moving
Fig. 5
3
0 I
5
35
CONTROL UNIT
Fig.4
1
UNCOVER COVER
4
2
