Installation Requirements
Before the installation, make sure that you have the following
conditions ready:
Workstations running Windows XP/2003/2008/2012/Vista/7/8/10/11, MAC OS X or
later, Linux, UNIX, or other platforms are compatible with TCP/IP protocols.
Workstations are installed with Ethernet NIC (Network Interface Card).
Serial Port Connection (Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232 converter.
The above Workstations have been installed with a terminal emulator, such as
HyperTerminal included in Windows XP/2003.
Serial cable -- one end is attached to the RS232 serial port, while the other end is
attached to the console port.
Ethernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45 connectors.
NOTE:
It is recommended to use Internet Chrome 98.0.xxx or above to access
the switch. If the web interface is not accessible, please turn o the anti-virus
software or rewall and then try it again.
