LEDs State
AC
DC1
DC2
Fault
System Ring
R.O.
DIDO
Green
Blinking Green
RJ45
Orange
Blinking Orange
Green
Blinking Green
SFP Combo
Orange
Blinking Orange
Description
Green AC power input is powered on.
Green
DC input 1 is powered on.
Green DC input 2 is powered on.
Red Switch AC/DC or port has failed.
Green ERPS Ring has been created successfully.
Green Ring state is in idle mode.
Blinking Green Ring state is in protected mode.
Switch AC/DC or port has failed or DI has
Blinking Red
an error.
The port is running at 1000Mbps and
established successfully.
The switch is actively sending or receiving
data at 1000Mbps.
The port is running at 10/100Mbps and
established successfully.
The switch is actively sending or receiving
data 10/100Mbps.
The port is running at 1000Mbps and
established successfully.
The switch is actively sending or receiving
data at 1000Mbps .
The port is running at 100Mbps and
established successfully.
The switch is actively sending or receiving
data at 100Mbps.
