Connecting the Console Port
3
4 5 6
3
4 5 6
AC
DC1
Ring
DC2
R.O .
+
-
Faul t
DC2
Fau lt
DID O
1
2
3
4
5
6
7
8
9
10
11
1. Insert the RJ45 connector into the RJ45 console port on the front of the switch.
2. Connect the DB9 female connector of the console cable to the serial port on the computer.
Con guring the Switch
Con guring the Switch via the Web-based Interface
Step 1: Connect the computer to an RJ45 port of the switch using the network cable.
Step 2: Set the IP address of the computer to 192.168.1.x ("x" is any number from 2 to 254,
except 100)
