Preparation
To start squeezing you must follow the steps below:
1
Unpack your juicer and place it on a surface as horizontal as possible.
2
Ensure that the mains power falls within the margins indicated on the Iden-
tification Label of the machine which you will find both on the cover page of
this manual as well as on the machine itself.
3
Place the peel buckets as indicated in Fig. 1 and 4.
4
Make sure that the juice container and its filter are placed correctly and that
the cover is closed and secured by the catch.
ZUMEX ESSENTIAL BASIC. Before starting the unit, place the orange feeding
tube in the position shown on Fig. 2. Use the 4 mm Allen key supplied with the
machine.
If you have acquired a juicer with a podium, you must place the juicer on the po-
dium, screw it as indicated in the instruction supplied on the podium. Don't forget
to secure the front wheels. Then place the hopper and the peel buckets with an
open base which you will find inside the stand (Fig. 5).
Operation
Essential Basic
Place a glass / jug under the juice outlet and press the green button (Fig. 3). The
machine will start to operate when you press the button. To stop the juicer, press
the red button.
Essential Pro y Versatile Pro
Once the previous steps have been followed, connect the connecting plug to a socket
base fitted with a standardized ground. And press the sleeve button
to start up the machine. When you turn on the machine for the first time after
purchase, a message will appear: "Select language" in order to select the operating
language of the machine.
The choice can be made using the arrows
the machine will be ready for operation in "Self-Service" mode.
and pressing "ON". Once selected,
