Create WIND ROUND Bedienungsanleitung Seite 7

F IX ING TH E MOUNTING B R ACKE T
• The outlet box and beam must be securely mounted and capable of reliably supporting at
least the weight of the fan.
Wooden ceiling
Securely attach the mounting bracket with
wood screws and washers to the ceiling
joints.
Do not fix the mounting bracket directly on ceilings with a thickness less than 10mm to avoid
the risk of the screw loosening.
ASE M B L I NG AND H ANGING TH E FAN
Cotter pin
• If you wish to extend the hanging length of your fan, you must remove the hanging ball
from the downrod provided to use with an extended downrod (included).
(If you wish to use the downrod, please proceed to instructions below.)
• To remove the hanging ball, loose the set screw on the hanging ball and remove the pin
and bolt. Lower hanging ball and remove stop pin. Slide hanging ball off the original
downrod, and slide it down the longer downrod (the top of the downrod should be noted
as having a fixing screw hole; use this hole when setting the fixing screw).
Drill holes with an 8mm drill, depending on
the length of the expansion screws. Next,
secure the mounting bracket to the ceiling
with the expansion screws.
Cotter pin
Concrete ceiling
Electrical wiring
Canopy
Hanging ball slot
Decorative cover
Bolt
Adapter
Fixing screw
E NG L I SH
7
