Mark the correct position of the holes and fix the ceiling bracket using the screws with metal
plugs or screws and washers suitable for the type of ceiling chosen.
Check the correct installation of the bracket before hanging the fan. This plate must support
the full weight of the fan.
INSTAL L ATIO N PRE PAR ATIO N
• To avoid personal injury and damage, make sure the place to hang the sheets leaves a
clearance of 2.3 m from the ground and 76 cm from any walls or obstructions.
• Make sure the mounting bracket is securely attached to the building structure and can
support the full weight of the fan.
DOWNRO D I NSTALL ATIO N
• Remove the seat post bolt by removing the pin and pass the finial (crown molding) and
hood through the hanger bar. Next, route the fan motor wires through the inside of the
hanger bar. Tighten the hanger bar to the engine and insert the bolt and pin.
Standard
mounting style
The standard mount hangs from the ceiling
using a rod.
6 E NGL I SH
INSTALLATION INSTRUCTIONS
76 cm
from wall
or nearest
obstruction 2.3 m from the
Support brace
blades to the
ground
20°
Angle
mounting style
Angle mounting is recommended for a
vaulted or angled ceiling.
Support
brace
