Adjustment of the operating distance
Attention:
Do not change the distance to the detecting object or the filling level during the adjustment.
The adjustment can be carried out optionally with the teach magnet or with the teach wire.
The teach connection can be made by holding the magnet on the teach spot or by making contact
between the teach wire and the operating voltage UB+.
Empty adjustment - Active surface free
The active surface of the sensor is free.
• Activate the EasyTeach menu and keep it active until the LED flashes green (see EasyTeach chart).
The output A1 pulses accordingly.
• Disconnect the teach connection.
• During the initialization process the LED is flashing green with higher frequency. The output A1 pulses
accordingly.
The empty adjustment is finished when the LED is static green. With this adjustment the sensor has the
largest sensing distance that is possible at the current mounting position. The switching hysteresis is
calculated automatically.
Full adjustment - Active surface covered
The active surface of the sensor must be covered completely with the product to be detected or the product
must be in the desired position.
• Activate the EasyTeach menu and keep it active until the LED flashes yellow (see EasyTeach chart).
The output A1 pulses accordingly.
• Disconnect the teach connection.
• During the initialization process the LED flashes yellow with higher frequency. The output A1 pulses
accordingly.
The full adjustment is finished when the LED is static yellow. The sensor is now optimally adjusted for
the detection of the product currently being used and the current mounting conditions. The switching
hysteresis is calculated automatically.
Test function
The test function can be used to check that the sensor is connected correctly.
• Activate the EasyTeach menu and keep it active until the LED flashes green and yellow at the same
time (see EasyTeach chart).
The test function switches output A1 in synchronisation with the LED. The test function is activated until
you disconnect the teach connection. The adjusted values stay unchanged.
i
After making the adjustment put the EasyTeach wire on GND of the supply voltage (-). This
prevents unintentional adjustments on the device.
Maintenance, repair, disposal
• Maintenance for this device is not necessary when used as intended.
• It is not possible to repair the device. If you have any problems, please contact directly your customer
service.
• Please dispose of the device in a way that is environmentally friendly according to the national
regulations.
