QMC41-100-I06
Technical Data
Normal Environmental Conditions
This product is designed to be safe under the following
conditions:
• Indoor use
• Altitude up to 2 000 m
• Operating temperature +5 °C / +41 °F to +40 °C / +104
°F
• Storage temperature -25 °C / -13 °F to +60 °C / +140 °F
• Maximum relative humidity 80 % for temperatures up to
31 °C / 89 °F decreasing linearly to 50 % relative humid-
ity at 40 °C / 104 °F
• Mains supply voltage fluctuations up to ±10 % of the
nominal voltage
• Transient overvoltages up to the levels of overvoltage
category II
• Temporary overvoltages occurring on the mains supply
• Pollution degree 2
• Ingress protection rating: IP20
Product data
Motor voltage
Motor power
Speed
Torque range
Weight
Declarations
Liability
Many events in the operating environment may affect the
tightening process and shall require a validation of results. In
compliance with applicable standards and/or regulations, we
hereby require you to check the installed torque and rotational
direction after any event that can influence the tightening re-
sult. Examples of such events include but are not limited to:
• initial installation of the tooling system
• change of part batch, bolt, screw batch, tool, software,
configuration or environment
• change of air- or electrical connections
• change in line ergonomics, process, quality procedures or
practices
• changing of operator
• any other change that influences the result of the tighten-
ing process
The check should:
• Ensure that the joint conditions have not changed due to
events of influence.
• Be done after initial installation, maintenance or repair of
the equipment.
24 V d.c.
145 W
2000 r/min
25 - 100 Nm (2.2 - 8.9 in lb)
0.61 kg (1.36 lb)
© Atlas Copco Industrial Technique AB - 9834 3502 00
• Occur at least once per shift or at another suitable fre-
quency.
EU DECLARATION OF INCORPORATION
We, Atlas Copco Industrial Technique AB, SE-105 23
STOCKHOLM SWEDEN, declare under our sole responsi-
bility that this product (with name, type and serial number,
see front page) fulfils the following essential requirements of
Machinery Directive 2006/42/EC:
2006/42/EC (MD)
And that this partly completed machinery is in conformity
with the provisions of the following other EU Directive(s):
2011/65/EU (RoHS), 2014/30/EU (EMC), 2015/863/EU
(RoHS amendment)
This partly completed machinery must not be put into service
until the final machinery into which it is to be incorporated
has been declared in conformity with provisions of the Ma-
chinery Directive 2006/42/EC, where appropriate.
The following (parts/clauses of) European harmonized stan-
dards have been applied:
EN 55014-1:2021, EN 55014-2:2021, EN 61000-6-2:2019,
EN 61326-1:2021 (Class A), EN IEC
61000-3-2:2019+A1:2021, EN IEC
61000-3-3:2013+A1:2019+A2:2021, EN ISO 12100:2010,
IEC 61010-1:2010+A1, IEC 61010-2-201:2017
The relevant technical documentation was compiled and was
communicated in accordance with Machinery Directive
2006/42/EC part B of Annex VII. Authorities can request the
technical file in electronic form from:
Aleksandra Duric, Product Compliance Manager, Atlas
Copco Industrial Technique AB, SE-105 23 Stockholm Swe-
den
Stockholm, 1 September 2023
Håkan Andersson, Managing Director
Signature of issuer
Noise Declaration Statement
• Sound pressure level <70 dB(A) , uncertainty dB(A), in
accordance with ISO15744.
• Sound power level dB(A) , uncertainty dB(A), in accor-
dance with ISO15744.
These declared values were obtained by laboratory type test-
ing in accordance with the stated standards and are suitable
for comparison with the declared values of other tools tested
in accordance with the same standards. These declared values
are not adequate for use in risk assessments and values mea-
sured in individual work places may be higher. The actual ex-
posure values and risk of harm experienced by an individual
user are unique and depend upon the way the user works, the
workpiece and the workstation design, as well upon the expo-
sure time and the physical condition of the user.
Safety Information
