• Wear safety goggles and a respirator when working
with the compressed air pistol. Dusts are harmful
to health! Injuries can be easily caused by foreign
objects and blown away parts.
• Do not blow at people with the blow-out pistol and
do not clean clothes while being worn. Risk of injury!
Safety instructions when using spraying attach-
ments (e.g. paint sprayers)
• Keep the spray attachment away from the compres-
sor when filling so that no liquid comes into contact
with the compressor.
• Never spray in the direction of the compressor when
using the spraying attachments (e.g. paint sprayers).
Moisture can lead to electrical hazards!
• Do not process any paints or solvents with a fl ash
point below 55 °C. Risk of explosion!
• Do not heat up paints or solvents. Risk of explosion!
• If hazardous liquids are processed, wear protective
filter units (face guards). Also, adhere to the safety
information provided by the manufacturers of such
liquids.
• The details and designations of the Ordinance on
Hazardous Substances, which are displayed on the
outer packaging of the processed material, must be
observed. Additional protective measures are to be
undertaken if necessary, particularly the wearing of
suitable clothing and masks.
• Do not smoke during the spraying process and/or in
the work area. Risk of explosion! Paint vapours are
easily combustible.
• Never set up or operate the equipment in the vicinity
of a fire place, open lights or sparking machines.
• Do not store or eat food and drink in the work area.
Paint vapours are harmful to your health.
• The work area must exceed 30 m³ and suffi cient
ventilation must be ensured during spraying and
drying.
• Do not spray against the wind. Always adhere to the
regulations of the local police authority when spray-
ing combustible or hazardous materials.
• Do not process media such as white spirit, butyl al-
cohol and methylene chloride with the PVC pressure
hose. These media will destroy the pressure hose.
• The work area must be separated from the compres-
sor so that it cannot come into direct contact with the
working medium.
Do not lose these safety instructions
Residual risks
Comply with the stipulated maintenance and safety
instructions in the operating instructions.
Remain attentive at all times when working and keep
third parties at a safe distance from your work area.
Even when the device is being used properly, there
will always be certain residual hazards that cannot be
completely ruled out. The following potential hazards
can arise due to the type and design of the device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing protec-
tion is not worn.
• Dirt particles, dust etc. can get into the eyes or face
despite wearing safety goggles.
• Inhaling swirled up particles.
6. Technical data
Mains connection
Motor rating
Operating mode*
Compressor speed
Operating pressure
Theoretical intake capacity
Theoretical delivery rate
Protection type
Protection class
Weight of the unit
*S3 15% = periodical intermediate duty with a duty cy-
cle of 15% (1.5 min based on a 10 minute period)
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The effects of noise can cause a loss of hearing.
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Sound power level L
Sound pressure level L
Uncertainty K
www.scheppach.com
220 - 240 V~ 50 Hz
approx. 180 l/min
approx. 115 l/min
wA
pA
wA/pA
max. 1100 W
S3 15%
3750 min
-1
approx. 8 bar
IP20
II
5.5 kg
96 dB
73.6 dB
1.96 dB
GB | 23
