Here's how to cut correctly!
DANGER! Risk of injury! Always
switch the motor off before you put
the device down!
• Search the work area and remove objects
which are in your way.
• When you begin work, check the safety of
the device (► Check before use! – p. 62).
• Take the device in both hands as
instructed.
Cutting hedges
NOTICE! Risk of damage to the
appliance! Take particular care
close to fences!
If trimmings, fence wire or similar is
caught in the cutting equipment,
switch the appliance off immediately.
– Remove blade guard.
– Do not push the point into the hedge.
– After switching off wait until the blade is
stationary.
– Mount blade guard.
Tips on hedge trimming
NOTICE! Risk of environmental
damage! Do not use the hedge
trimmer during normal periods of
quiet and rest.
Before cutting a hedge, check that
there are no birds nesting.
1
2
1. Cut the hedge to the desired height.
2. Trim the side of the hedge diagonally from
bottom to top.
3. Round off the upper corners of the hedge.
4. Cut back the hedge somewhat at ground
level.
Cleaning and maintenance
DANGER! Risk of injury! Before
any maintenance or cleaning work:
• Remove the battery.
• Let the device cool down.
64
3
4
Overview of cleaning
If necessary
What?
Clean the machine ► Cleaning the device –
Oil cutting tool
Annually
What?
Re-tension saw chain ► Re-tensioning the
Clean oil guide
groove of the saw bar.
Sharpen the saw
chain.
Cleaning
Cleaning the device
– Remove coarse dirt.
– Wipe down the device with a slightly
damp cloth.
Cleaning the oil guide groove of the saw
bar
– Remove the saw bar.
– Clean dirt from the oil guide groove of the
saw bar with a suitable tool. (plastic spat-
ula, do not use any steel tools!)
– Replace saw bar(► Assembling the saw
bar and saw chain – p. 60).
Re-tensioning the saw chain
► P. 5, fig. 6
– Lift the tip of the saw bar slightly.
– Tighten the tensioning screw for chain
tension (27) until the chain lies on the
underside of the saw bar.
Sharpening the saw chain
Special tools are required to sharpen the saw
chain; these guarantee that the cutting of the
chain occurs at the correct angle and the cor-
rect depth. We recommend that you have the
saw chain sharpened by a professional.
Storing, transport
Storing
DANGER! Danger of injury!
Make sure no unauthorised persons
can gain access to the appliance!
– Slip the protection cover over the cutting
equipment.
How?
p. 64
Clean cutting tool with
brush. Then, spray oil on
all sides of the cutting tool.
How?
saw chain – p. 64
► Cleaning the oil
guide groove of the
saw bar – p. 64
► Sharpening the
saw chain – p. 64
