Tensioning the saw chain
► P. 5, fig. 6
– Tighten the tension ring (27) until the
chain lies on the underside of the saw bar.
– Tighten the fastening nut (14).
Letting the saw chain run in
During the run-in time, re-tension the saw
chain and rail after a maximum of 5 cuts.
Checking the tensioning of the saw chain
The saw chain is tensioned correctly if it lies
close against the underside of the saw bar
and can be moved easily by hand.
Readjust tension of the saw chain when neces-
sary (► Re-tensioning the saw chain – p. 64).
Checking the chain greasing
The device may not be used without sufficient
chain greasing. Insufficient greasing reduces
the service life of the device.
– Check the oil quantity in the tank.
– Start the device.
– Hold the running saw chain approx. 15 cm
over a suitable surface for a time (15 s).
If there is sufficient chain greasing, the oil spray-
ing off of the saw chain will form a slight trail.
Filling up saw chain oil
► P. 5, fig. 7
NOTICE! Environmental damage!
Since the saw chain oil can penetrate
the environment during operation, bio-
logically-degradable special vegetable-
based saw chain oils should be used.
– Lay device securely with the tank
cover (28) upwards.
– Before opening, clean the tank cover and
the filler neck if necessary.
– Slowly open and remove the tank cover.
– Carefully fill up the saw chain oil. Do not spill!
– Read the oil level at the inspection glass (29).
The oil stand must be placed above [MIN].
– Tighten the tank cover by hand.
– If you have spilled any saw chain oil, be
sure to wipe it up.
Operation
Charging the battery pack
Note: Rechargeable battery and
charger are not part of the scope of
delivery and are available optionally
from your dealer (► Accessories –
p. 66).
CAUTION! Risk of injury! Com-
ply with all safety instructions when
handling rechargeable devices.
NOTICE! Risk of damage to the
unit! Do not allow the battery pack
to deep discharge.
NOTICE! Risk of damage to the
unit! Do not press the On/Off
switch after the device has deacti-
vated automatically.
Note: The Li-Ion battery pack can
be charged at any time without
affecting the lifetime of the unit.
Interrupting the charging process
will not damage the battery pack.
Note: If the battery is fully loaded,
the charger automatically switches
over to the maintenance charge
function. The battery can thus
remain in the charger permanently.
The battery pack must be charged prior to the first
start-up (charging time: ► Technical data – p. 66).
► P. 6, fig. 8
– Press in the locking button (19) and
remove the battery from the device.
► P. 6, fig. 9
– Insert the battery pack into the charger.
– Plug the charger into the power supply.
The charging status is displayed by the con-
trol lights (20).
– Slot the battery pack into the device and
make sure it clicks into place correctly.
Checking the remaining capacity of the
battery
– Press the button (9).
The remaining capacity of the battery is dis-
played by the control lights (8).
Adjusting the length of the telescopic rod
► P. 4, fig. 3
WARNING! Risk of injury! Before
each use, make sure that the tele-
scopic rod is securely clamped and
cannot come loose during opera-
tion.
– Loosen the locking lever (3).
– Pull out telescopic rod (10) of desired length.
– Tighten the locking lever (3) again.
Adjusting working position of the drive unit
► P. 3, fig. 1
