► P. 3, fig. 1
1. Cutting equipment
2. Drive unit for hedge trimmer
3. Lock for length setting
4. Unlock nut for drive unit
5. Shoulder strap lug
6. Rear handle adjustment knob
7. Switch-on safety lock
8. On/Off switch
9. Battery pack (only for item 196100)
10. Grip for front hand
11. Unlock button for drive unit
12. Blade protection
13. Drive unit for chain saw
14. Quick locking device for saw bar
15. Saw bar
16. Protective cover
► P. 3, fig. 2
17. Display for remaining capacity
18. Push button for capacity display
19. Locking button
20. Control lights
21. Battery charger (only for item 196100)
What is included
• Drive unit for chain saw
• Drive unit for hedge trimmer
• Telescopic rod
• Protective cover
• Blade protection
• Saw bar
• Saw chain
• Instructions for use
• Battery pack (only for item 196100)
• Battery charger (only for item 196100)
Installation
► P. 4, fig. 3
60
DANGER! Risk of injury during
operation! Improperly mounted
parts can cause severe and even
fatal injuries when using the device!
This device may only be commis-
sioned if all parts are mounted com-
pletely and tightly and no part is
damaged!
• Therefore, read the whole chap-
ter before you assemble the
parts!
• Assemble the parts carefully
and completely.
• Use tools when their use is sug-
gested.
CAUTION! Risk of injuries due to
cuts! The teeth of the saw chain
are very sharp! Protective gloves
must be worn for all work on the
chain.
WARNING! Risk of injury! An
improperly mounted saw chain
causes uncontrolled cutting behav-
iour of the device! When assem-
bling the chain, heed the prescribed
running direction!
Fitting the shoulder strap
– Hook the shoulder strap into the lug (5).
Assembling telescopic rod
– align with the arrows on the drive unit (13)
and telescopic rod (10).
– Fit the drive unit (13) onto the telescopic
rod(10)and let it lock into place.
– Screw in the locking nut (4) towards [ ].
Assembling the saw bar and saw chain
► P. 4, fig. 4
– Loosen the nut (14) on the chain wheel
guard (22) and remove chain wheel guard.
► P. 5, fig. 5
– Place Saw bar (15) on the guide rail (24)
with the guide groove (23).
Note: When attaching the chain,
heed the correct position of the
guide groove (saw bar).
– Place the saw chain (25) around the chain
wheel (26). Heed the assembly direction.
– Place the saw chain (25) around the saw
bar (15).
► P. 5, fig. 6
– Attach the chain wheel guard (22).
– Tighten the fastening nut (14) only slightly.
