• The unit should be cleaned with a dry piece of cloth or blown with
low-pressure compressed air.
• Do not use any cleaning agents or solvents, as these may
damage the plastic parts.
• Clean the ventilation slots in the motor housing regularly to
prevent the unit from overheating.
• If excessive sparking occurs on the commutator, have the
condition of the motor's carbon brushes checked by a qualified
person.
• Always store the device in a dry place out of the reach of children.
• Store the device with the battery removed.
Any defects should be rectified by the manufacturer's authorised
service department.
TECHNICAL SPECIFICATIONS
RATING DATA
Parameter
Battery voltage
Speed
Impact frequency
Impact energy
Tool holder type
Maximum drilling Steel
diameter
Concrete
Wood
IP degree of protection
Protection class
Mass
Year of production
NOISE AND VIBRATION DATA
Sound pressure level
Sound power level
Vibration acceleration value (rear
handle)
Vibration acceleration value (front
handle)
Information on noise and vibration
The levels of emitted noise, such as the sound pressure level
L and the sound power level L
pA
uncertainty K , are given below in the instructions in
accordance with EN 60745.
The vibration values a and the measurement uncertainty K
h
determined in accordance with EN 60745-2-6 are given below.
The vibration level given below in these instructions has been
measured in accordance with the measurement procedure
specified by EN 60745 and can be used to compare power tools. It
can also be used for a preliminary assessment of vibration
exposure.
The vibration level indicated is representative of the basic use of
the power tool. If the power tool is used in other applications or with
other working tools, and if it is not sufficiently maintained , the
vibration level may change. The reasons given above may result in
increased vibration exposure during the entire working period.
To accurately estimate exposure to vibration , it is necessary to take
into account periods when the power tool is switched off or when it
is switched on but not used for work. In this way, the total vibration
exposure may be considerably lower. Additional precautions should
be taken to protect the user from the effects of vibration, such as:
maintaining the power tool and work tools, ensuring an adequate
hand temperature, proper work organisation .
Sound pressure level: Lp = 85.0 dB(A) ; K = 3 dB(A) Sound
A
power level: Lw = 96.0 dB(A) ; K = 3 dB(A) Vibration
A
acceleration value (rear handle):
value
18 V DC
-1
0-900 min
-1
0-5000 min
0,8 J
SDS Plus
8 mm
10 mm
16 mm
IPX0
III
1,210 kg
2023
L = 85.0 dB(A), K= 3
PA
dB(A)
L = 96.0 dB(A), K= 3
WA
dB(A)
2
a = 8.64 m/s K=
h,HD
2
1.5 m/s
= 7.43 m/s² , K=
a
h,HD
1.5 m/s²
and the measurement
wA
2 2
a = 8.64 m/s K= 1.5 m/s
h
Vibration acceleration values (front handle): a
2 2
7.43 m/s K= 1.5 m/s
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
substances that are not environmentally friendly. Unrecycled
equipment poses a potential risk to the environment and human
health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with
its registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex")
informs that all copyrights to the content of this manual (hereinafter: "Manual"),
including, among others. Its text, photographs, diagrams, drawings, as well as its
composition, belong exclusively to Grupa Topex and are subject to legal protection
under the Act of 4 February 1994 on Copyright and Related Rights (Journal of Laws
2006 No. 90 Poz. 631, as amended). Copying, processing, publishing, modification
for commercial purposes of the entire Manual and its individual elements, without the
consent of Grupa Topex expressed in writing, is strictly prohibited and may result in
civil and criminal liability.
EC Declaration of Conformity
Manufacturer: Grupa Topex Sp. z o.o. Sp.k., Pograniczna 2/4 02-
285 Warszawa
Product: Cordless hammer drill
Model: 58G009
Trade name: GRAPHITE
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility
of the manufacturer.
The product described above complies with the following documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And meets the requirements of the standards:
EN 60745-1:2009+A11:2010; EN 60745-2-6:2010;
EN 55014-1:2017+A11:2020; EN 55014-2:2015;
EN IEC 63000:2018
This declaration relates only to the machinery as placed on the market
and does not include components
added by the end user or carried out by him/her subsequently.
Name and address of the EU resident person authorised to prepare
the technical dossier:
Signed on behalf of:
Grupa Topex Sp. z o.o. Sp.k.
2/4 Pograniczna Street
02-285 Warsaw
Paweł Kowalski
TOPEX GROUP Quality Officer
Warsaw, 2023-11-30
ÜBERSETZUNG (BENUTZERHANDBUCH)
AKKU-BOHRHAMMER
HINWEIS: BEVOR SIE DAS GERÄT BENUTZEN, LESEN SIE
BITTE DIESE ANLEITUNG
BEWAHREN SIE SIE ZUM SPÄTEREN NACHSCHLAGEN AUF.
BESONDERE SICHERHEITSBESTIMMUNGEN
BESONDERE VORSICHTSMASSNAHMEN
ARBEITEN MIT DEM HARTBOHRER Vorsicht:
Die Batterie, die das Gerät mit Strom versorgt, muss vor der
Durchführung von Einstellungs-, Betriebs- (Bohrerwechsel) oder
Reparaturarbeiten entfernt werden.
• Tragen Sie bei der Arbeit einen Gehörschutz. Lärmbelastung
kann zu Gehörverlust führen.
