Freeze mode
If the cable connection between the computer module and the console module is inter-
rupted during operation, the KVM extender no longer displays an image at the remote
console.
Enable the Freeze mode if you want the last image that has been displayed at the console
module to be available until the connection is re-established.
To highlight an interrupted connection, the last available image can be displayed
with either a coloured frame and/or a
connection has been interrupted.
How to configure the Freeze mode:
1. Press
Ctrl+Num
2. Select the row
The following options can be adjusted separately for both video channels, if you use the
optional Transm. Redundancy feature
3. Under Freeze mode
 Freeze mode is disabled (default)
off
on  Freeze mode is enabled
4. If the Freeze mode is active, press
under Freeze visualization
 shows a coloured frame when disconnected
frame
OSD  shows Frozen and the time passed since disconnection
frame+OSD  shows a coloured frame (
5. Press F2 to save your settings.
Frozen
(default) to open the OSD.
and press
Console setup
.
press F8 to select on of the following options:
F8 to select one of the options available
:
popup and the time passed since the
.
Enter
frame ) and Frozen ( OSD
G&D VisionXS-C-DP-UHR · 71
Configuration
)
