Checking the availability of a host in the network (Ping)
The OSD can be used to test the availability of a particular host (e. g., a computer or
a network device) in the network.
How to check the availability of a host in the network:
1. Use the (default:
local hotkey
use the remote hotkey
module.
2. Select the entry Network
.
Enter
3. Select the entry Ping host
4. Use the Host entry to enter the IP address or the host name and press
5. The test results are displayed in the following table:
Transmitted: number of transmitted data packets
Received: number of received data packets
Lost:
number of lost data packets
Min. RTT: minimum round-trip-time
Avg. RTT: average round-trip-time
Max. RTT:
maximum round-trip-time
NOTE: A message informs the user if the host name cannot be resolved into an
IP address.
6. Press to leave the menu.
Esc
Initial configuration of the network settings
+ ) to open the local OSD of the console module or
Alt Num
(default: Ctrl + Num ) to open the remote OSD of the computer
(local OSD) or Network setup
and press Enter .
(remote OSD) and press
Enter
