On-screen display
When starting the console module, information about the starting process as well as
the firmware versions and IDs of the connected modules are displayed in the monitor
of the console module.
Additionally, the
local hotkey
module and the remote OSD
OSD of the computer module are shown.
ADVICE: Press
Pause
Basic operating of the on-screen display
The on-screen display (OSD) – just like the web application
described on the following – can be used to change the configuration of the KVM
extender.
NOTE: The actual configuration options by the user depend on the granted rights
(see Changing the user account rights on page 41 ff.).
The OSD can be opened by pressing a configured hotkey at the console module.
You can view and edit the settings of the KVM extender only in the remote OSD of
the computer module.
IMPORTANT:
The OpenAccess operating mode is set by default. In this operating
mode, access to the KVM extender is not protected by authentication. Information
on the operating modes can be found in chapter Operating modes of console modules
on page 54 ff.
NOTE: Use the remote hotkey
ure the remote OSD of the computer module and the
to open and configure the local OSD of the console module.
During the starting process of the console module, the settings of both hotkeys are
shown (see Starting process on page 16).
(default: +
Alt Num
remote hotkey
to stop the process. Pressing
(default: Ctrl + Num
) to open the local OSD of the console
(default: Ctrl + Num ) to open the remote
continues the process.
Space
Config Panel
) at the console to open and config-
local hotkey (default:
G&D VisionXS-C-DP-UHR · 25
On-screen display
, which is
Alt + Num )
