Installation
Connecting the computer's video output
Line In Line In Serial Serial
Use the DP-Cable-M/M-2 cable to connect the computer's video output to
DP CPU:
this interface.
Connecting audio and RS232 interfaces (depending on model)
Line In Serial
Line In: Use an Audio-M/M-2 audio connection cable to connect the omputer's Line-
Out interface to this interface
Use the RS232-M/F-2 cable to connect one of the computer's 9-pin serial inter-
Serial:
faces to this interface.
8 · G&D VisionXS-C-DP-UHR
USB CPU USB CPU DP CPU
USB CPU USB CPU
DP CPU DP CPU
