EN
4.6 CUTTING TIPS
Figure 9.
• Tilt the machine towards the area to be cut. Use the
tip of the cutting line to cut grass.
• Move the machine from right to left to prevent
thrown debris toward the operator.
• Do not cut in dangerous areas.
• Do not force the trimmer head into uncut grass.
• Wire and picket fences cause cutting line wear and
breakage. Stone and brick walls, curbs, and wood
can wear the cutting line quickly.
4.7 ADJUST THE LENGTH OF THE CUTTING
LINE
Figure 10.
While you operate the machine, the cutting line gets
worn and shorter. You can adjust the length of the
cutting line.
1. Hit the trimmer head against the ground while you
operate the machine.
2. Line is automatically released and the cut-off
blade cuts the excess length.
4.8 ADJUST THE CUTTING DIAMETER
Figure 11.
The machine is set at a 356 mm cutting diameter.
You can adjust to a 406 mm cutting diameter.
Set the cutting diameter to 356 mm for greater
runtime and 406 mmfor a larger cutting area.
1. Remove the battery pack.
2. Remove the blade screws from the cut-off blade.
3. Turn the cut-off blade 180°.
4. Tighten the blade screws.
4.9 LINE CUT-OFF BLADE
Figure 11.
This trimmer is equipped with a line cut-off blade
on the guard. The line cut off blade continuously
trims the line to ensure a consistent and efficient cut
diameter. Advance line whenever you hear the engine
running faster than normal, or when trimming efficiency
diminishes. This will maintain best performance and
keep the line long enough to advance properly.
English
NOTE
5 MAINTENANCE
Read and understand the safety regulations and the
maintenance instructions before you clean, repair or
do the maintenance work on the machine.
Make sure that all nuts, bolts and screws are tight.
Check regularly that the handles are firmly mounted.
Use only the replacement parts and accessories of
the initial manufacturer.
5.1 GENERAL INFORMATION
Only your dealer or approved service center can do
the maintenance that is not given in this manual.
Before the maintenance operations:
• Stop the machine.
• Remove the battery pack.
• Cool the motor.
• Store the machine in a cool and dry place.
• Use correct clothing, protective gloves and safety
glasses.
5.2 CLEAN THE MACHINE
• Clean the machine after each use with a moist cloth
dipped in neutral detergent.
• Do not use aggressive detergents or solvents like
"glass cleaner" to clean the plastic parts or handles.
• Keep the trimmer head free from grass, leaves, or
excessive grease.
• Keep the air vents clean and free of debris to avoid
overheating and damage of the motor.
• Do not spray water onto the motor and electrical
components.
5.3 REPLACE THE SPOOL
Figure 12 - 20.
1. Push the tabs on the sides of the trimmer head at
the same time.
2. Pull and remove the spool cover.
3. Remove the remaining spool.
4. Install the new spool.
5. Put the spool in the spool cover.
