Cable requirements
Communication interfaces for RS-485:
Ethernet (TruConvert System Control)
Cable requirements
Troubleshooting
In the event of warning or alarm messages: See the "Troubleshooting" chapter of the operator's manual for the
device.
1 Power flow battery → DC link
2 Communication between the
inverters
DC link application with storage connection
A67-0140-00.BK-002
-01
■ Twisted pair patch cable in accordance with standard TIA/
EIA-568A/B
■ CAT 5 or higher
■ Maximum length: 30 m
■ Twisted pair patch cable in accordance with standard TIA/
EIA-568A/B
■ CAT 5 or higher
■ Maximum length: 100 m
1.2 The TruConvert system
A TruConvert DC 10xx
B System control
