5 Startup

Set up the Sterisart universal pump ergonomically in a suitable area (cleanroom,
laminar flow work bench, isolator).
Before initial start-up, the accessories supplied must be assembled on the Sterisart
Universal pump. Please proceed in the following order:
At the back left, push the stand (Fig. 1, 7) onto the pins of the upper part of the pump
until it is firmly in place. The holes in the foot of the stand can be used to change the
position of the stand.
–  First, fasten the holding ring for bottles to the stand (Fig. 1, 8), next fasten the con-
trol unit clamp (Fig. 1, 12) with the display and control unit (Fig. 1, 11; only for ver-
sion 16420) and the fastening arm (Fig. 1, 9). Then make the electrical connection
to the pump via the control unit's cable and plug contact (Fig. 1, 13). If necessary,
attach the ampoule breaker (Fig. 1, 10) beforehand.
–  Insert the bow (Fig. 1, 4) and the clamping lever (Fig. 1, 3) on the corresponding
bolts on the top of the pump. The lever is jacketed in a plastic sleeve that can be
removed for cleaning. If signs of wear appear on this sleeve after it has been in use
for some time, it can be re-ordered as a spare part (see Chapter 14).
–  After attaching the drain tubing to the flange connection (Fig. 1, 15) on the drain-
ing container (Fig. 1, 14), attach the draining container to the appropriate bolt
with tilting lock on the right handle (Fig. 1, 5). The draining container and the
cover plate are attached by moving the tilting lock.
–  Fasten the end of the drain tubing to the appropriate drain.
Very Important Note!
Always make sure that there is a sufficient liquid level differential (> 5 cm)
between the draining container and the drain. This makes safe drainage possible
and prevents backflow into the draining container. Make sure that the drain
tubing is kept lower than the pump to prevent the drain pan from overflowing.
Treat the waste as a biohazard. Only dispose of it in accordance with current
regulations.
Startup
11
