MAP Mix Provectus
Location Register write
0x0020
"Mixer table 1"
offset values
(write only)
0x0030
"Mixer table 2"
offset values
(write only)
0x0040
Vacuum buffer
set pressure
(Write only)
0x0041
Vacuum buffer
hysteresis
(Write only)
0x0042
Vacuum buffer
min on time
(times 100ms)
(Write only)
0x0043
Vacuum buffer
min off time
(times 100ms)
(Write only)
0x0050
Set mixer type
(Write only)
0x0051
Set input range for
voltage input. 0-
10/2-10V
0x0066
Output valve
mode (write)
Dansensor A/S
DE
Encoding
Not used in MMP
Not used in MMP
4 byte float. Saved in non volatile memory.
Actual set point for the pressure in the vacuum buffer.
Typical 3.0 or 5.0 bars.
4 byte float. Saved in non volatile memory.
Typical 0.3 bar. When buffer pressure reach "Vacuum buffer
set pressure" - "Vacuum buffer hysteresis" the valve is turned on.
When the pressure reaches "Vacuum buffer set pressure" it is
turned off.
Not used in MMP, setting is ignored.
Not used in MMP, setting is ignored.
1 byte unsigned. Saved in non volatile memory.
0 = Not used in MMP (Ignored)
1 = CO
/N
2
2
2 = N
/O
2
2
3 = CO
/O
2
2
4 = N
/CO
/O
2
2
2
NOTE! It is NOT allowed to send 2-gas modes to a 3-gas mixer
or vice versa
1 byte unsigned. Saved in non volatile memory
0 = 0 to 10V
1 = 2 to 10V (default)
NOTE! If V-in (voltage input) is not used, always select the range
2 to 10 V and short circuit the input.
1 byte unsigned.
See also read 0xAD06
0 = Stop mixer
1 = Start mixer
COPYRIGHT ©
Bedienungsanleitung
PBI-300863-B 02/2013
41
