Location Register read
0xA04B
0xA009
0xA01F
Write commands (W (Operational commands))
Location Register write
0x0000
0x0010
0x0011
PBI-300863-B 02/2013
Encoding
"Mixer table 2" Not used in MMP
offset
(read only)
Mixer table 1 Not used in MMP
(read only)
Mixer table 2 Not used in MMP
(read only)
Encoding
Mix 1 setting 1 unsigned byte
Range 0 to 100%
For a 3-gas mixer this controls the setting of "GAS 2 INPUT" i.e.
%CO
For a 3-gas mixer:
When writing new "Mix 1 setting" MAP mix 8000 will not change
"Mix 2 setting", and vice versa, if possible.
i.e. %O
new "Mix 1 setting" or "Mix 2 setting" setting. If/when %O
minimum % or 100%, when adjusting to a new "Mix 1 setting", "Mix
2 setting"( %N
The sum of %N
Mix 2 setting 1 unsigned byte
(3-gas mixer only) Range 0 to 100%
Only used when a 3-gas mixer is connected. In case send to a 2-gas
mixer, the mixer will return a ACK, but the received setting is ignored
For a 3-gas mixer this parameter controls the setting of
"GAS 1 INPUT" i.e. %N
See "Mix 1 setting" encoding column, how setting of "Mix 2 setting"
will change the setting of "Mix 1 setting"
