Product Diagram
Robot
TrueMapping
TrueDetect 3D
Sensor
Anti-collision
Sensors and Bumper
Buttons
Short press: Exit/Return to the Station
Short press: Start/Pause/Continue
Short press: Start/End Spot Cleaning
RESET Button
Restore to default settings: Press and hold RESET button for 5 seconds.
After you hear the voice prompt, the startup music will be played and the robot will be
restored to default settings.
Microphone
Charging
Contacts
Water Filling Port
Top Cover
Buttons
Edge Sensor
Long press: Power on/Power off
Long press: Child Lock
Data Transfer Port
For professional
maintenance personnel
use only.
Wi-Fi Status
Indicator
Bottom View
Anti-drop Sensors
Carpet Detection
Sensor
Brush
Mounting Slots
for Mopping Pad
Assembly
Dust Bin
Filter
Sponge Filter
Mopping Pad Assembly
Mopping Pad Plates
Universal Wheel
Side Brush
Brush Release
Button
Driving Wheels
Dust Disposal Port
Dust Bin Handle
Filter Net
Release Button
Washable Mopping Pads
