5 • Final check
1
D1
2
Put back the removable profile
3
If the motor cable is visible and installed outdoors, the cable needs to be protected
by conduit or trunking.
4
Check if the end points are set. If they are not set, set the end points so the motor
automatically stops in the desired highest and lowest position (see documents on
motor adjustment).
5
Make sure to set the lower end point at a 10 mm from the end of the side guiding
channels so the fabric remains at the correct tension.
6
Check if all screws, bolts and nuts are firmly tightened.
7
Roll the screen up and down several times to ensure proper operation.
H1
D2
H2
of the side guiding channels (Torx key T20).
➂
Before starting the motor, check if the
set-up is square. The diagonals (D1 and
D2) and parallels (H1 and H2) should
be as equal as possible for the fabric to
properly unwind.
D1 = D2 and H1 = H2
