6. Installation
This chapter describes how to install the sauna heater. Place the heater under the recliner bench.
The sauna heater is not designed to be installed or set up in an alcove or under a sloping roof,
unless this sauna heater is specifically designed and approved for this type of installation. Prior to
installation, air inlets and outlets must be attached to the cabin.
NOTICE
Damage due to incorrect mounting location
► The heater is not suitable for outdoor use.The heater must be operated only inside sauna cabins and
may not be exposed to environmental conditions such as extreme humidity and moisture or the pos-
sible formation of condensation or corrosive substances in the ambient air, as well as other weather
conditions.
► The heater is not designed to be installed or set up in an alcoveor under a bench or sloping roof.
6.15 Specifications for the cabin
The cabin must be planned and installed according to specifications before the heater is installed.
All electrical installations laid inside the cabin must be suitable for a temperature of at least 170°C.
All lines must be routed in such a way that they are well-protected, e.g. in a cable duct.
If single-core lines are used as connecting cables, they must be protected by a flexible metal hose
that is connected to the protective conductor.
In general, it should be noted that the sauna heater must not be set on a floor made of highly
flammable material such as laminate, flooring made of plastic material, etc. Ceramic tiles are re-
commended as a flooring option. Floor heating in the sauna cabin increases the temperature of
the floor's surface temperature.
Installation site
►
Ceiling height min. 210 cm
ƒ
Distance heater – cabin wall min. 7 cm
ƒ
The clearance distance between the heater and flammable material (wood wall, recliner
ƒ
bench, etc.) must be at least 2 cm.
The supplied protective grill must be mounted above the heater on the top edge of the
ƒ
dividing wall facing the sauna's rear wall. This prevents objects from falling onto the heater.
The required cabin volume depends on the heater output. See 4. Technical data
ƒ
