Technical data
4. Technical data
Heater power as per DIN
Electrical connection
For sauna volume
Minimum size of air inlet and outlet
Weight, without stones and packaging
Heater dimentions, H x W x D
Stone volume (not included))
Power extension box (PEB)
For use with the sauna control units
Leakage current
Intended use / area of application
Fuse protection for control unit
Fuse protection for PEB unit
Connection mains – control unit
Connection mains – PEB unit
Connection control unit – heater
Connection PEB unit – heater
Connection control unit – PEB unit
All line cross-section specifications are the minimum cross-sections for the copper line.
15.0 kW
400 V 3N ~ 50 Hz
18 - 25 m³
60 x 5 cm
44.0 kg
87 x 144 x 20 cm
~ 20 kg (calibre 50-100 mm)
EOS Econ D series (D2 - D4), EOS Compact D series, EOS EmoTec
D series, EOS EmoStyle D series, EOS EmoTouch 3 series
max. 0.75 mA per kW heater output
Use in private and commercial sauna cabins
5 x 2.5 mm²
5 x 2.5 mm²
5 x 1.5 mm² pre-mounted
5 x 1.5 mm² pre-mounted
4 x 1.5 mm²
18.0 kW
24 - 30 m³
2 x
45.0 kg
PEB 10
3 x 16 A
3 x 16 A
