Pedestrian gate mode
In this mode, when a remote control button or application button is pressed, a pulse of the dura-
tion specified by "Pulse time" parameter is generated. The mode used to trigger electric strike of
pedestrian gate.
Gate mode (pedestrian gate function)
1. Operation the same as gate mode
2. Partial opening of a gate
In case of partially opening, after pressing the remote control button or the button in the applica-
tion, a pulse of the duration defined by the "Pulse time" parameter is generated.
disappears, the time specified by the "Delay time" parameter is set and a pulse of the duration
specified by the "Pulse time" parameter is automatically generated again.
Gate
closed
NOTE: Additional pulse is generated only if the limit switches are configured (at least
one set on CLOSING) and the gate is Closed.
Monostable mode
Pulse generation – pulse duration depends on how long the button (on the remote control or in
application) is pressed. Maximum pulse duration – 120 s.
Pressing
the button
The mode is set individually for each channel by selecting "Configure" from the options menu.
Gate mode
Pulse time – this parameter defines the pulse duration (time of closing
output contact) It can be set from 0.1 s to 300 s with 0.1 s increment.
Partial opening of a gate – inactive
Pulse duration: 0,1 ÷ 300 s
Delay time:
1 ÷ 300 s
Pulse duration: 0,1 ÷ 300 s
Releasing the
button
przycisk wciśnięty
Pressing
the button
Pulse stops automatically
after 120 s
After it
