ULTIMATE SPEED UPK 10 D1 Bedienungs- Und Sicherheitshinweise Originalbetriebsanleitung Seite 19

Step
1. Connect the
jump lead
18
of the power
bank with com-
pressor to
1
the car-jump-
start-outlet
8
of the power
bank with com-
pressor .
1
2. First connect
the red clamp
(A) to the posi-
tive pole of the
vehicle battery
and then con-
nect the black
battery clamp
(B) to the neg-
ative pole
(see Fig. 1).
3. Starting up the
vehicle.
LEDs
Red Error LED is
20
continuously lit on
the jump lead .
18
Green Start LED
and the red
19
flash
Error LED
20
alternately.
The red Error
LED flashes,
20
a short alarm
signal sounds.
The red Error
LED flashes,
20
a continuous alarm
signal sounds.
The red Error
LED
flashes
20
once, a continuous
alarm is sounded
and then followed
by two short alarm
sounds.
Green Start LED
and the red
19
Error LED flash
20
alternately. After
1–2 seconds only
the green LED
19
glows.
Meaning /
Error
The voltage
determined in
the power bank
with compressor
is not enough
1
to start the car.
Power bank with
compressor
1
ready.
The tempera-
ture is too high,
possibly due to
several jump
start attempts.
Battery clamps
(A) and (B) are
the wrong way
round.
It is caused by
a short circuit
or the battery is
leaking.
The connection
is correct
Using the device
Solution
Charge the
power bank
with compres-
sor .
1
Carry on with
step 2
Disconnect
the black (B)
battery clamp
first and then
the red clamp
(A) from the
battery poles.
Start again
from step 1.
Carry on with
step 3.
GB 19
