6. Operation
6.1 Before switching on for
the first time
CAUTION:
After unpacking, there could still be oil
residues on the shaving heads 4 of the
shaving attachment 5. Remove these
with an absorbent, lint-free cloth before
using the device for the first time.
Regardless of the charging state of the bat-
tery, the rotary shaver can always be used
in mains operation.
1. Before switching to mains operation,
ensure that the device is switched off.
2. Connect the power unit 19 to the con-
nection 14 at the device.
3. Insert the power unit 19 into a readily
accessible wall socket whose voltage
matches the voltage stated on the rating
plate.
4. Figure A: push the protective cap 15
downwards off the shaving attach-
ment 5.
5. Switch on the device with the on/off
switch 9.
6.2 Transport lock
If the transport lock is activated, the lock
symbol 12 flashes.
• Press and hold the on/off switch 9 for
approx. 4 seconds, in order to switch
the transport lock on/off.
• Connecting the power unit 19 deacti-
vates the transport lock, which cannot be
activated during mains operation.
8
GB
6.3 Changing the shaving/
beard trimmer
attachment
WARNING! Risk of injury!
Switch off the shaver 8, before you at-
tach or remove the attachments.
1. Figure A: slide the protective cap 15
onto the shaving attachment 5 from be-
low, with the opening first.
2. Figure B: turn the attachment 3 or 5 a
little bit anticlockwise and then pull it
off the shaver 8.
3. Figure C: insert the attachment 3 or 5
with the groove into the recess of the
motor unit for attachments 7. Turn the
attachment a little bit clockwise. Ensure
that the attachment is firmly attached to
the shaver 8.
6.4 Pushing on/removing the
comb attachment
WARNING! Risk of injury!
Switch off the device before replacing
or changing a comb attachment 1.
Pushing on
• In order to attach the comb attach-
ment 1, push it over the guide rails on
the side of the device onto the beard
trimmer attachment 3, until it is heard to
click into place.
Removing
1. Push the comb attachment 1 upwards
using a moderate amount of force. The
comb attachment 1 separates from the
beard trimmer attachment 3.
2. Remove the comb attachment 1.
