TECHNICAL DATA
Item number
Product type
Line inputs
Line outputs
Line output connectors
Powered outputs
Cooling system
HDMI Specifications
Supported Color Format
Max. Data Rate
Resolution range
Color bit depth
Chroma Sampling
Standards
Number of HDMI Inputs
HDMI Input Connector
Number of HDMI Outputs
HDMI Output Connector
Standby wake up time
Line Out Specifications
THD+N
SNR (A)
Frequency response
Output Level
3rd Party Control
Main Volume (VCA)
Source Select
Power Standby
Amplifier Output
Type
Output Modes
Amplifier Outputs
Connector
16
LDAMP205AV
Installation power amplifier and HDMI Audio-Deembedder
0
2
Balanced line outputs, pitch 3.81 mm terminal block (3-pin)
2 with output mode selector (Stereo / High Power Mode)
Convection cooling
RGB, YUV444, YUV422, YUV420
48 Gbit/s
Up to 4K2K 60 Hz
8 bits per color
4 : 4 : 4
HDMI 2.1, HDCP 1.4 – 2.3
1
1 female HDMI type A
1
1 female HDMI type A
7 seconds
> 0.006%
< 100 dB
20 Hz – 20 kHz (-1 dB)
+15 dBu (0 dBFS / 1 kHz)
10k (Linear Taper) External Potentiometer, pitch 3.5mm terminal block
(3-pin)
Pitch 3.5 mm terminal block (3-pin)
External momentary button, pitch 3.5 mm terminal block (2-pin)
Class D
Stereo, Parallel, High Power Mode (ST / HPM)
2- channel (STEREO) / 1-Channel (HPM)
4-pin Terminal block (pitch 5.08 mm)
