STANDBY BUTTON AND POWER SYMBOL
11
Press the button to activate standby mode and again to end standby mode. The power symbol
lights up red when standby mode is activated. As soon as the standby mode is ended and the
device is operational, the symbol lights up white.
VOLUME
12
Level control for adjusting the volume. Turning to the right increases the volume, turning to the
left decreases it.
SIG (SIGNAL)
13
As soon as an audio signal is present at the device, the signal indicator lights up white.
HPM
14
As a visual indication that the high power mode is activated, the HPM indicator lights up white
(see point 7 SETTINGS).
PROT (PROTECT)
15
The Protect indicator lights up permanently if the system is overloaded or overheats, in case
of a short circuit in the loudspeaker path and in case of a defect. The amplifier is automatically
muted. Disconnect the amplifier from the power supply and let it cool down for some time.
Eliminate a possible short circuit in the loudspeaker path. Reconnect the amplifier to the power
supply. If the Protect indicator still lights up, there is a defect in the amplifier electronics.
Contact an authorised service workshop.
AIR VENTS
To prevent damage to the device, do not cover the ventilation openings on the left and right
sides and on the top and bottom of the device and ensure that air can circulate freely. Covering
the ventilation openings on the top or bottom of the enclosure when mounting it underneath
or on top of a table is not critical, as the cooling provided by the ventilation openings on the
remaining sides is sufficient.
13
14
12
15
11
11
