The outside of the device should be cleaned periodically to remove contaminants such as dust etc.
1
Disconnect the device from power and allow it to cool before cleaning.
2
Clean the surface with a soft lint-free and moistened cloth. Never use alcohol or solvents as these may
damage the surface. Make sure that no liquids can enter the device.
3
The device must be dry before reapplying power.
There are no serviceable parts inside. Do not open the housing. Do not try to repair the device by yourself as this
may result in damage. Maintenance and service operations are only to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts. Should you have further questions, please contact
your dealer.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating. Before replacing
the fuse, unplug mains lead.
Procedure:
• Step 1: Open the fuse holder on the rear panel with a fitting screwdriver.
• Step 2: Remove the old fuse from the fuse holder.
• Step 3: Install the new fuse in the fuse holder.
• Step 4: Replace the fuse holder in the housing.
Power supply:
Power consumption:
IP classification:
Control:
DMX channels:
Parallel operation:
Carrier frequency:
Modulation:
Coverage:
Antenna:
Latency:
DMX connection:
Dimensions (L x W x H):
Weight:
Specifications are subject to change without notice due to product improvements.
Accessories
No. 58000754
No. 58010372
Best.-Nr. 51834031
Best.-Nr. 51834037
CLEANING AND CARE
TECHNICAL SPECIFICATIONS
DMX Split 6
100-240 V AC, 50/60 Hz
Max. 10 W
IP20
CRMX by LumenRadio + W-DMX (G4S/G3) by Wireless Solution + RDM
512
Max. 10 DMX universes
2.4 GHz ISM band
GFSK
up to 500 m (line-of-sight)
5 dBi
<5 ms
3-pin XLR (pin 1: ground, pin 2: signal -, pin 3: signal +)
137 x 122 x 112 mm (without antenna)
1.22 kg
TH-270S Quick-Lock Slim black
Safety Bond UNV-5 3x600mm up to 5kg silver
WDS-CRMX TX IP Wireless DMX Transceiver Outdoor
WDS-CRMX TX Wireless DMX Transceiver
19 • EN
