Status displays
LEDs of »Select« buttons
Each Select button provides two LEDs.
The LEDs ahve the following meaning:
LED Status
Above On
Off
Below On
Off
12 · G&D OperatorPanel




Meaning
Active channel.
Inactive channel.
Channel is selected by user or connected device.
Channel is not selected by user.
