1. Wait for the device to shut-down.
2. Clockwise direction: Press
direction switch (4) to the left.
3. Anticlockwise direction: Press
direction switch (4) to the right.
4. Switch lock: Bring direction switch
(4) to neutral position.
The direction changed may only be
performed in standstill mode.
Torque setting
You can preset the maximum torque by
rotating the torque adjustment ring (2).
20+1 torque levels are provided.
1. Turn the adjusting ring (2) to select the
desired torque:
Step 1 -->
-->
Step
Screws:
Drilling:
2. Start with a lower torque step and in-
crease according to requirement.
Torque adjustment should only be
performed in standstill mode.
Reaching the preset torque limit pro-
duces a noticeable rasping sound.
This sound is caused by the slip
clutch.
Tool change
The automatic spindle lock enables the tool
to be changed even when the motor is at a
standstill.
1. Rotate the keyless chuck (1) towards
RELEASE
until the drill chuck aperture
(11) is large enough to accommodate
the tool.
26
lowest torque,
highest torque.
Steps 1 - 20
Step
2. Push the tool as far as possible into the
keyless chuck (1).
3. Turn the keyless chuck towards
order to clamp the tool.
4. To remove the tool again, rotate the
keyless chuck (1) and pull out the tool.
Switching on/off
By using the on/off switch (8) you can
progressively control the speed. The longer
you push the on-off button, the higher the
speed.
1. Press the on/off switch (8) to start the
device. The LED work light (10) lights
up during operation.
2. To turn it off, release the on/off switch
(8). The working light (10) remains il-
luminated for around 10 seconds after
releasing the on/off switch (8).
When you move the direction switch
(4) to the middle position, the device is
secured against being switched on.
Cleaning and
maintenance
Contact our Service Centre about
repairs and servicing not described
in this manual. Only use OEM
parts. Risk of injury!
Turn off the appliance and, before
doing any servicing, remove the
battery.
The following cleaning and servicing
should be done regularly. This will ensure
a long and reliable service life.
in
GRIP
