8. Unpacking

• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety products (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m WARNING!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
choking or suffocating!
9. Assembly (Fig. 3 - 5)
• Place the middle frame (2) and the bottom frame (3)
with the undersides on the floor.
• Slide the middle frame (2) between the steel spars of
the bottom frame.
• Pull the locking pin (6) of the bottom frame (3) out
to the maximum and slowly release it again until it
engages in the locking hole of the middle frame (2)
(see fig. 3).
• Connect the bottom frame and the middle frame
with the screws (A), washers (B) and locking nuts
(C) (see fig. 3).
• Turn the already assembled frames with the tops
onto the floor.
• Slide the top frame between the steel spars of the
middle frame.
• Connect the middle frame and the top frame with the
screws (A), washers (B) and locking nuts (C) (see
fig. 4).
• Insert four rollers each into the bottom frame. Using
the Allen key (G), screw the sleeve nuts (D) and the
spring washers (E) onto the threads of the rollers.
Counter the rollers with the open-ended spanner (F).
Screw the remaining two rollers directly into the top
frame with the open-ended spanner (F) (see fig. 5).
• Turn the assembled product over so that it is stand-
ing on the rollers. The product is ready for use as a
rolling board.
10. Start up (Fig. 6 & 7)
m Attention!
Always make sure the product is fully assembled
before commissioning!
Make sure that the product is installed completely and
properly. Before each use, always check:
• The product for possible damage,
• Whether all screws are tightened,
• Visibility of all labels
10.1 Conversion from a rolling board to a stool
• Pull out the locking pin (6) of the bottom frame (3) to
the maximum and keep it in position.
• Fold the middle frame upwards (see fig. 6).
• Slowly release the locking pin until it engages with
the safety hook (see fig. 4).
• Fold down the top frame until it reaches a horizontal
position (see fig. 7). The product is ready for use as
a stool.

11. Cleaning

• We recommend that you clean the product directly
after every use.
• Wipe dust off the product from time to time with a
cloth.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product.

12. Storage

Store the product as a stool. Place the product on its
side on the frame so that it cannot tip over or roll away.
Choose a clean, dry place without direct sunlight.
www.scheppach.com GB | 17
