5. Installation electrical
Make sure that you never exchange
the Positive (+) and Negative (-) of
the electricity supply!
Make sure that all cables are installed properly,
solidly and without any friction.
Carefully seal any holes with suitable sealing
material, from the inside and the outside.
E5
Basic station
Fix the housing lid of the Basic Station.
Mount the antennae cable in accordance with the
notes on the Basic Station. In case of a poor
radio signal, you may connect an optional
amplifier (item no. 527-0200).
E6
Connection D-Plus (Safety circuit,
optional)
If the D-Plus signal of the vehicle has been
connected to the contact and a signal is supplied,
the MoveControl cannot be started. This kind of
safety circuit prevents any operation being not
appropriate.
Use of this function requires connection of the D+
signal, as well as an additional ground connection
(GND) to the pulling vehicle.
E7
Connection battery
Now connect the 10 mm² cables to the
battery.
The
electrical
completed.
installation
is
now
GB7
